Shear, Bend and Tensile Testing

Shear testing and pull testing are parts of Destructive Physical Analysis (DPA) for passive or active electronic components and cable assemblies. They evaluate the strength of solder joints or leads against tugging or pushing. Pull tests are done in tension and shear tests in compression. Other materials such as paper, plastic films and metal wire are submitted to tensile tests to verify their elasticity. Bend tests are performed on printed circuit boards to assess the resistance of capacitors to cracking.

Typical applications

  • Quality assessment
  • Ruggedness
  • MIL-STD-883 method 2019 Die shear
  • MIL-STD-883 method 2011 Bond wire pull
  • AEC Q-200 Method 005 Board Flex Test
  • AEC Q-200 Method 006 Passive Component Terminal Strength Shear Test
  • MIL-STD-750 Method 2036 Terminal Strength
  • MIL-STD-883 method 2004 lead Integrity
